3.95 Walk Interval: An interval during which the WALKING PERSON (symbolizing WALK) signal
indication is displayed. When a verbal message is provided at an accessible pedestrian signal, the verbal
message is “walk sign.”
3.96 warning beacon: A beacon used only to supplement an appropriate warning or regulatory sign or
marker.
3.97 WAVE device: A device that contains a WAVE-conformant medium access control (MAC) and
physical layer (PHY) interface to the wireless medium. (See IEEE 802.11 and IEEE 1609.4)
3.98 WAVE management entity (WME): The set of management functions, as defined in IEEE Std 1609
documents, required to provide WAVE Networking Services.
3.99 WAVE service information element (WSIE): A collection of configuration data transmitted by
either OBU or RSU, which includes the Provider Service Table, and in the case of the RSU the WAVE
Routing Advertisement, as well as security credentials.
3.100 wireline: Connected via a traditional communications interface; not the wireless interface specified
here.
3.101 XML: A common method of exchanging messages made up of tags and values organized in a data
structure and typically transported over common Internet formats such as HTTP. XML has a growing
number of supporters due to its ability to be implemented in the types of heterogeneous systems often
found in ITS deployments. It is possible to express and exchange the DSRC message sets using this
method; XML schema definitions are provided in the latter clauses of the standard.
3.102 yellow change interval: The first interval following the green interval during which the yellow
signal indication is displayed. In the SPAT message the fixed duration of the yellow change interval is
(optionally) provided for each active lane being described.
3.2 Abbreviations and acronyms
The terms, abbreviations and acronyms cited below shall be a part of the terms of this standard (and of the
other companion volumes and guides) unless specifically cited otherwise.
AAMVA
American Association of Motor Vehicle Administrators
ABS
Anti-lock Braking System
ACID
Application Class Identifier
ACM
Need Define here
ASTM
American Society for Testing and Materials
 |
