Road Sign Example
This sample packet contains two generic road signs. The first road sign has a single valid region defined
by a four-point polygon. The second road sign’s valid region is a circle.
The basic content of the signs is the text string included in their “content” sections.
The signs also contain the optional off-board URLs for descriptive images. Some vehicles may be able to
retrieve these images through an alternative mechanism – WiMax, WiFi, Cellular modem, etc., or by way
of the TCIP/IP stack over DSRC.
Figure 4: Road Sign Example
