ITIS Phrase Tables, Draft [issued: 04-11-09]
-
128 -
This is a draft document of the SAE ATIS committee, subject to change.
<xs:simpleType>
<xs:restriction base="xs:string">
<xs:pattern value="\[.+\].*"/>
</xs:restriction>
</xs:simpleType>
<xs:simpleType>
<xs:restriction base="local:LaneRoadway" />
</xs:simpleType>
</xs:union>
</xs:simpleType>
Used By: This entry is used directly by one other data structure in this standard, a DF called
DF_ITIS_EventType <ASN> <XML>. In addition, this item may be used by data structures in other
ITS standards.
6.19 Data Element: DE_Large Numbers
Use: The ITIS enumeration list commonly referred to as "Large Numbers," is assigned the upper byte
value of [45] (which provides for value ranges from 11520 to 11775, inclusive). This list is formally called
"LargeNumbers" in the ASN.1 and XML productions. The items in this enumeration list are not allowed to
be used as an event category classification. This list contains a total of 90 different phrases. The remaining
37 values up to the lower byte value of [127] are reserved for additional "national" phrases in this byte
range. Local phrases may be added to the list starting with the lower byte value of 128 and proceeding
upward from there (in other words, the first value assigned for any local additions to this list would be
given the value 11648).
ASN.1 Representation:
LargeNumbers ::= ENUMERATED {
n1-16th (11521), -- NEW: The fraction 1/16th
n1-10th (11522), -- NEW: The fraction 1/10th
n1-8th (11523), -- NEW: The fraction 1/8th
n1-4th (11524), -- NEW: The fraction 1/4th
n1-3rd (11525), -- NEW: The fraction 1/3rd
n1-2 (11526), -- NEW: The fraction 1/2
n3-4 (11527), -- NEW: The fraction 3/4th
n300 (11531), -- NEW:
n350 (11532), -- NEW:
n400 (11533), -- NEW:
n450 (11534), -- NEW:
n500 (11535), -- NEW:
n550 (11536), -- NEW:
n600 (11537), -- NEW:
n650 (11538), -- NEW:
n700 (11539), -- NEW:
n750 (11540), -- NEW:
n800 (11541), -- NEW:
n850 (11542), -- NEW:
n900 (11543), -- NEW:
n950 (11544), -- NEW:
n1000 (11545), -- NEW:
n1100 (11546), -- NEW:
n1200 (11547), -- NEW:
n1300 (11548), -- NEW:
n1400 (11549), -- NEW:
n1500 (11550), -- NEW:
n1600 (11551), -- NEW:
n1700 (11552), -- NEW:
n1800 (11553), -- NEW:
n1900 (11554), -- NEW:
n2000 (11555), -- NEW:
n2100 (11556), -- NEW:
n2200 (11557), -- NEW:
n2300 (11558), -- NEW:
n2400 (11559), -- NEW:
n2500 (11560), -- NEW:
