"MUTCDLocations" in the ASN.1 and XML productions. The items in this enumeration list are not
allowed to be used as an event category classification. This list contains a total of 69 different phrases,
divided into 2 further sub-categories (the division into these sub-categories is informational only and other
groupings may also be used). The remaining 58 values up to the lower byte value of [127] are reserved for
additional "national" phrases in this byte range. Local phrases may be added to the list starting with the
lower byte value of 128 and proceeding upward from there (in other words, the first value assigned for any
local additions to this list would be given the value 13696).
ASN.1 Representation:
MUTCDLocations ::= ENUMERATED {
-- Signage Locations
ahead (13569), -- NEW: Location and used as
-- arrow
here (13570), -- NEW: Location and used as
-- arrow
here-to (13571), -- NEW: Followed by specific
-- object
here-to-alley (13572), -- NEW:
here-to-corner (13573), -- NEW:
here-to-sign (13574), -- NEW:
between-signs (13575), -- NEW:
between (13633), -- NEW: Followed by object, and,
-- another object
this-side-of-street (13576), -- NEW:
this-side-of-sign (13577), -- NEW:
right (13579), -- NEW:
left (13580), -- NEW:
begin-point (13581), -- NEW: Use for "begins" as
-- well. Do not use for
-- times/dates
next (13582), -- NEW: May be followed by a
-- distance value
starting-start (13611), -- NEW: Do not use for
-- times/dates
ends-end (13583), -- NEW: Do not use for
-- times/dates
other-Side (13584), -- NEW:
crossing (13585), -- NEW:
crosswalks (13586), -- NEW:
center-strip (13587), -- NEW: Alt form: center stripe
lane (13588), -- NEW: Used for lanes as well
shelter (13634), -- NEW: Typically preceded by a
-- specific type
center (13635), -- NEW: Typically preceded by a
-- specific type
-- Signage Arrows
hill (13589), -- NEW:
both-ways-left-and-right (13590), -- NEW:
both-ways-45-degree-angle-tilting-right (13591), -- NEW:
both-ways-45-degree-angle-tilting-left (13592), -- NEW:
both-directions-of-travel (13593), -- NEW: As in Centerline - left
-- turn arrows - both directions
-- of travel or for two-way
-- traffic
left-arrow (13610), -- NEW:
left-turn (13594), -- NEW: For W1R
left-45-degree-arrow (13595), -- NEW:
left-45-degree-turn (13596), -- NEW:
ahead-and-to-the-left (13597), -- NEW:
ahead-and-to-the-left-at-a-45-degree-angle (13598), -- NEW:
right-arrow (13609), -- NEW:
right-turn (13599), -- NEW: For W1R
right-45-degree-arrow (13600), -- NEW: For W1-2
right-45-degree-turn (13601), -- NEW:
ahead-and-to-the-right (13602), -- NEW:
ahead-and-to-the-right-at-a-45-degree-angle (13603), -- NEW:
downward-left-45-degree (13604), -- NEW:
