<xs:enumeration value=“prohibit LU LT L45 S R45 RT RU Allowed None" id="_11391"/>
</xs:restriction>
</xs:simpleType >
<xs:simpleType>
<xs:restriction base="xs:string">
<xs:pattern value="\[.+\].*"/>
</xs:restriction>
</xs:simpleType>
<xs:simpleType>
<xs:restriction base="local:ValidManeuvers" />
</xs:simpleType>
</xs:union>
</xs:simpleType>
In addition, this item may be used by data structures in other ITS standards.
Remarks:
The above maneuvers are abbreviated as follows:
LU
= Left Hand U-Turn
Bit 7
LT
= Left Hand Turn
Bit 6
L45
= Left Hand 45 degree turn (soft left) or curve
Bit 5
S
= Straight Ahead
Bit 4
R45
= Right Hand 45 degree turn (soft right) or curve
Bit 3
RT
= Right Hand Turn
Bit 2
RU
= Right Hand U-Turn
Bit 1 (the LSB bit)
6.51 Data Element: DE_Vehicle Groups Affected
Use: The ITIS enumeration list commonly referred to as "Vehicle Groups Affected," is assigned the upper
byte value of [36] (which provides for value ranges from 9216 to 9471, inclusive). This list is formally
called "VehicleGroupAffected" in the ASN.1 and XML productions. Items from this enumeration list can
be used as an event category classification. This list contains a total of 45 different phrases. The remaining
82 values up to the lower byte value of [127] are reserved for additional "national" phrases in this byte
range. Local phrases may be added to the list starting with the lower byte value of 128 and proceeding
upward from there (in other words, the first value assigned for any local additions to this list would be
given the value 9344).
ASN.1 Representation:
VehicleGroupAffected ::= ENUMERATED {
all-vehicles (9217),
bicycles (9218),
motorcycles (9219), -- to include mopeds as well
cars (9220), -- (remapped from ERM value of
-- zero)
light-vehicles (9221),
cars-and-light-vehicles (9222),
cars-with-trailers (9223),
cars-with-recreational-trailers (9224),
vehicles-with-trailers (9225),
heavy-vehicles (9226),
trucks (9227), -- Use for RG-190
buses (9228),
articulated-buses (9229),
school-buses (9230),
vehicles-with-semi-trailers (9231),
vehicles-with-double-trailers (9232), -- Alternative Rendering: western
-- doubles
high-profile-vehicles (9233),
