8.12 Data Element: DE_ITIS_Text [ITIS]
Use: Simple text used with ITIS codes.
ASN.1 Representation:
ITIStext ::= IA5String (SIZE(1..500))
XML Representation:
<xs:simpleType name="ITIStext" >
<xs:restriction base="xs:string">
<xs:minLength value="1"/>
<xs:maxLength value="500"/>
</xs:restriction>
</xs:simpleType>
Used by: This entry is used directly by one other data structure in this standard, a DF called DF_ITIS-Codes_And_Text
[ITIScodesAndText] <ITIScodesAndText>. In addition, this item may be used by data structures in other ITS
standards.
8.13 Data Element: DE_Responder Group Affected [ITIS]
Use: The ITIS enumeration list commonly refered to as "Responder Group Affected," is assigned the upper byte
value of [38] (which provides for value ranges from 9728 to 9983, inclusive). This list is formally called
"ResponderGroupAffected" in the ASN.1 and XML productions. Items from this enumeration list can be used as an
event category classification. This list contains a total of 14 different phrases. The remaining 113 values up to the
lower byte value of [127] are reserved for additional "national" phrases in this byte range. Local phrases may be
added to the list starting with the lower byte value of 128 and proceeding upward from there (in other words, the
first value assigned for any local additions to this list would be given the value 9856).
ASN.1 Representation:
ResponderGroupAffected ::= ENUMERATED {
emergency-vehicle-units (9729), -- Default phrase, to be used when one of
-- the below does not fit better
federal-law-enforcement-units (9730),
state-police-units (9731),
county-police-units (9732), -- Hint: also sheriff response units
local-police-units (9733),
ambulance-units (9734),
rescue-units (9735),
fire-units (9736),
hAZMAT-units (9737),
light-tow-unit (9738),
heavy-tow-unit (9739),
freeway-service-patrols (9740),
transportation-response-units (9741),
private-contractor-response-units (9742),
... -- # LOCAL_CONTENT_ITIS
}
-- These groups are used in coordinated response and staging area information
-- (rather than typically consumer related)
XML Representation:
<xs:simpleType name="ResponderGroupAffected" >
<xs:union>
<xs:simpleType>
<xs:restriction base="xs:unsignedInt">
<xs:minInclusive value="9728"/>
<xs:maxInclusive value="9983"/>
</xs:restriction>
</xs:simpleType>
<xs:simpleType>
<xs:restriction base="xs:string">
