Probe Data Message Sets
Research has indicated that the optimal DSRC packet size is around 400-500 bytes to account for the
effects of high-speed vehicles. Each Probe Data Message payload is limited to four (4) snapshots in order
to accommodate security and other message overhead in this packet size limitation. If a vehicle contains
more than 4 snapshots, it will send multiple messages. These multiple messages, each containing a
maximum of 4 snapshots, make up the Probe Data Message Set that is sent to an RSE. For Example if the
vehicle contains 30 probe data snapshots, it will send a Probe Data Message Set comprised of 8 individual
Probe Data Messages to the RSE. Figure 1 contains the layout of a Probe Data Message.
Probe
Header
Message
Header
Snapshot 1
Snapshot 3
Snapshot 2
Snapshot 4
Over the Air
Probe Message
Each snapshot contains the value of the respective sensor
at the time the snapshot was taken. Data Elements consist
of items such as:
-Lat
-Long
-Time
-Wipers
-Brake Applied
-Air Temp
...
The Probe Header consists of the following
items:
-ACID
-ACM
-Message Length
-Seconds since last Probe Message sent
Content provided
by lower layers
Fig 1: Probe Message Layout
