<xs:annotation>
<xs:documentation>
To be made up of packed bytes as follows:
longOffset INTEGER (-32767..32767)
latOffset INTEGER (-32767..32767)
zOffset INTEGER (-127..127)
time INTEGER (1..32758)
</xs:documentation>
</xs:annotation>
<xs:extension base="BreadCrumbVersion-4-string" >
<xs:attribute name="EncodingType" use="required">
<xs:simpleType>
<xs:restriction base="xs:NMTOKEN">
<xs:enumeration value="base64Binary"/>
</xs:restriction>
</xs:simpleType>
</xs:attribute>
</xs:extension>
</xs:simpleContent>
</xs:complexType>
<xs:simpleType name="BreadCrumbVersion-4-string">
<xs:restriction base="xs:base64Binary">
<xs:length value="10"/>
</xs:restriction>
</xs:simpleType >
Used By: This entry is used directly by one other data structure in this standard, a DF called
DF_VehicleMotionTrail <ASN> <XML>. In addition, this item may be used by data structures in
other ITS standards.
7.26 Data Element: DE_BreadCrumbVersion-5
Use: The BreadCrumbVersion-5 data element one of a set of related items to carry breadcrumb data
(typically vehicle trials). In use, sequences of this data set are sent (one per crumb), typically combined
into a single final octet string.
ASN.1 Representation:
BreadCrumbVersion-5 ::= OCTET STRING (SIZE(13))
-- To be made up of packed bytes as follows:
-- longOffset INTEGER (-32767..32767)
-- latOffset INTEGER (-32767..32767)
-- zOffset INTEGER (-127..127)
-- accuracy PositionalAccuracy
XML Representation:
<xs:complexType name="BreadCrumbVersion-5" >
<xs:simpleContent>
<xs:annotation>
<xs:documentation>
To be made up of packed bytes as follows:
longOffset INTEGER (-32767..32767)
latOffset INTEGER (-32767..32767)
zOffset INTEGER (-127..127)
accuracy PositionalAccuracy
</xs:documentation>
</xs:annotation>
<xs:extension base="BreadCrumbVersion-5-string" >
<xs:attribute name="EncodingType" use="required">
<xs:simpleType>
<xs:restriction base="xs:NMTOKEN">
<xs:enumeration value="base64Binary"/>
</xs:restriction>
</xs:simpleType>
</xs:attribute>
</xs:extension>
</xs:simpleContent>
</xs:complexType>
 |
