-- upper nibble: Preempt #:
-- Bit 7 (MSB) 1 = Preempt and 0 = Priority
-- Remaining 3 bits:
-- Range of 0..7. The values of 1..6 represent
-- the respective controller preempt or Priority
-- to be activated. The value of 7 represents a
-- request for a cabinet flash prempt,
-- while the value of 0 is reserved.
-- lower nibble: Strategy #:
-- Range is 0..15 and is used to specify a desired
-- strategy (if available).
-- Currently no strategies are defined and this
-- should be zero.
XML Representation:
<xs:complexType name="SignalReqScheme" >
<xs:simpleContent>
<xs:annotation>
<xs:documentation>
Encoded as follows:
upper nibble: Preempt #:
Bit 7 (MSB) 1 = Preempt and 0 = Priority
Remaining 3 bits:
Range of 0..7. The values of 1..6 represent
the respective controller preempt or Priority
to be activated. The value of 7 represents a
request for a cabinet flash prempt,
while the value of 0 is reserved.
lower nibble: Strategy #:
Range is 0..15 and is used to specify a desired
strategy (if available) .
Currently no strategies are defined and this
should be zero.
</xs:documentation>
</xs:annotation>
<xs:extension base="SignalReqScheme-string" >
<xs:attribute name="EncodingType" use="required">
<xs:simpleType>
<xs:restriction base="xs:NMTOKEN">
<xs:enumeration value="base64Binary"/>
</xs:restriction>
</xs:simpleType>
</xs:attribute>
</xs:extension>
</xs:simpleContent>
</xs:complexType>
<xs:simpleType name="SignalReqScheme-string">
<xs:restriction base="xs:base64Binary">
<xs:length value="2"/>
</xs:restriction>
</xs:simpleType >
Used By: This entry is directly used by the following 2 other data structures in this standard (record type,
descriptive name, ASN.1, and XML name (if present) of each):
DF
DF
In addition, this item may be used by data structures in other ITS standards.
Remarks: In use, the the vehicle must determine which preempt number or priority number to request by
analyzing its location relative to the map layer information.
Note: if we get rid of having two complete request messages in favor of only one; we could use the MSB
bit here to differentiate between priority and preemption use cases.
 |
