units of 0.01 m/s
max delta value of 2.55 m/s
1 byte in length -->
</xs:sequence>
</xs:complexType>
Used By: This entry is used directly by one other data structure in this standard, a DF called
DF_VehicleMotionTrail <ASN> <XML>. In addition, this item may be used by data structures in
other ITS standards.
6.9 Data Element: DF_BSM_Blob
Use: The octet blob data element used in many places to define vehicle position and motion Used in the
basic safety message (hence the name BSM blob) as well as in other messages.
ASN.1 Representation:
BSMblob ::= OCTET STRING (SIZE(30))
-- made up of the following 30 packed bytes:
-- lat Latitude, -x- 4 bytes
-- long Longitude, -x- 4 bytes
-- elev Elevation, -x- 2 bytes
-- accuracy PositionalAccuracy, -x- 4 bytes
-- speed Speed, -x- 2 bytes
-- heading Heading, -x- 2 byte
-- accelSet AccelerationSet4Way, -x- accel set (four way) 7 bytes
-- brakes BrakeSystemStatus, -x- 2 bytes
-- size VehicleSize, -x- 3 bytes
XML Representation:
<xs:complexType name="BSMblob" >
<xs:simpleContent>
<xs:annotation>
<xs:documentation>
made up of the following 30 packed bytes:
lat Latitude, -x- 4 bytes
long Longitude, -x- 4 bytes
elev Elevation, -x- 2 bytes
accuracy PositionalAccuracy, -x- 4 bytes
speed Speed, -x- 2 bytes
heading Heading, -x- 2 byte
accelSet AccelerationSet4Way, -x- accel set (four way) 7 bytes
brakes BrakeSystemStatus, -x- 2 bytes
size VehicleSize, -x- 3 bytes
</xs:documentation>
</xs:annotation>
<xs:extension base="BSMblob-string" >
<xs:attribute name="EncodingType" use="required">
<xs:simpleType>
<xs:restriction base="xs:NMTOKEN">
<xs:enumeration value="base64Binary"/>
</xs:restriction>
</xs:simpleType>
</xs:attribute>
</xs:extension>
</xs:simpleContent>
</xs:complexType>
<xs:simpleType name="BSMblob-string">
<xs:restriction base="xs:base64Binary">
<xs:length value="40"/>
</xs:restriction>
</xs:simpleType >
Used By: This entry is directly used by the following 3 other data structures in this standard (record type,
descriptive name, ASN.1, and XML name (if present) of each):
 |
