bkLvl-7 (7), -- B'0111
bkLvl-8 (8), -- B'1000
bkLvl-9 (9), -- B'1001
bkLvl-10 (10), -- B'1010
bkLvl-11 (11), -- B'1011
bkLvl-12 (12), -- B'1100
bkLvl-13 (13), -- B'1101
bkLvl-14 (14), -- B'1110
maxPressure (15) -- B'1111 Maximum Braking Pressure
}
-- Encoded as a 4 bit value
XML Representation:
<xs:simpleType name="BrakeAppliedPressure" >
<xs:annotation>
<xs:appinfo>
notEquipped (0) -- B'0000 Not Equipped
minPressure (1) -- B'0001 Minimum Braking Pressure
bkLvl 2 (2) -- B'0010
bkLvl 3 (3) -- B'0011
bkLvl 4 (4) -- B'0100
bkLvl 5 (5) -- B'0101
bkLvl 6 (6) -- B'0110
bkLvl 7 (7) -- B'0111
bkLvl 8 (8) -- B'1000
bkLvl 9 (9) -- B'1001
bkLvl 10 (10) -- B'1010
bkLvl 11 (11) -- B'1011
bkLvl 12 (12) -- B'1100
bkLvl 13 (13) -- B'1101
bkLvl 14 (14) -- B'1110
maxPressure (15) -- B'1111 Maximum Braking Pressure
</xs:appinfo>
<xs:documentation>
Encoded as a 4 bit value
</xs:documentation>
</xs:annotation>
<xs:union>
<xs:simpleType>
<xs:restriction base="xs:unsignedInt">
<xs:minInclusive value="0"/>
<xs:maxInclusive value="15"/>
</xs:restriction>
</xs:simpleType>
<xs:simpleType>
<xs:restriction base="xs:string">
<xs:enumeration value="notEquipped"/>
<xs:enumeration value="minPressure"/>
<xs:enumeration value="bkLvl 2"/>
<xs:enumeration value="bkLvl 3"/>
<xs:enumeration value="bkLvl 4"/>
<xs:enumeration value="bkLvl 5"/>
<xs:enumeration value="bkLvl 6"/>
<xs:enumeration value="bkLvl 7"/>
<xs:enumeration value="bkLvl 8"/>
<xs:enumeration value="bkLvl 9"/>
<xs:enumeration value="bkLvl 10"/>
<xs:enumeration value="bkLvl 11"/>
<xs:enumeration value="bkLvl 12"/>
<xs:enumeration value="bkLvl 13"/>
<xs:enumeration value="bkLvl 14"/>
<xs:enumeration value="maxPressure"/>
</xs:restriction>
</xs:simpleType >
</xs:union>
</xs:simpleType>
