SAE J2735-Draft-Rev28 [issued: 11-10-08]
-
231 -
This is an SAE Motor Vehicle Council draft document of the DSRC committee, subject to change.
enters the transmission zone during the response to the event. Local agreements on practices, including
road side unit (RSU) placement, will be needed to insure correct operation.
8.11 Data Element: DE_Responder Group Affected [ITIS]
Use: The ITIS enumeration list commonly refered to as "Responder Group Affected," is assigned the
upper byte value of [38] (which provides for value ranges from 9728 to 9983, inclusive). This list is
formally called "ResponderGroupAffected" in the ASN.1 and XML productions. Items from this
enumeration list can be used as an event category classification. This list contains a total of 14 different
phrases. The remaining 113 values up to the lower byte value of [127] are reserved for additional
"national" phrases in this byte range. Local phrases may be added to the list starting with the lower byte
value of 128 and proceeding upward from there (in other words, the first value assigned for any local
additions to this list would be given the value 9856).
ASN.1 Representation:
ResponderGroupAffected ::= ENUMERATED {
emergency-vehicle-units (9729), -- Default phrase, to be used when one of
-- the below does not fit better
federal-law-enforcement-units (9730),
state-police-units (9731),
county-police-units (9732), -- Hint: also sheriff response units
local-police-units (9733),
ambulance-units (9734),
rescue-units (9735),
fire-units (9736),
hAZMAT-units (9737),
light-tow-unit (9738),
heavy-tow-unit (9739),
freeway-service-patrols (9740),
transportation-response-units (9741),
private-contractor-response-units (9742),
... -- # LOCAL_CONTENT_ITIS
}
-- These groups are used in coordinated response and staging area information
-- (rather than typically consumer related)
XML Representation:
<xs:simpleType name="ResponderGroupAffected" >
<xs:union>
<xs:simpleType>
<xs:restriction base="xs:unsignedInt">
<xs:minInclusive value="9728"/>
<xs:maxInclusive value="9983"/>
</xs:restriction>
</xs:simpleType>
<xs:simpleType>
<xs:restriction base="xs:string">
<xs:enumeration value="emergency vehicle units" id="_9729"/>
<xs:enumeration value="federal law enforcement units" id="_9730"/>
<xs:enumeration value="state police units" id="_9731"/>
<xs:enumeration value="county police units" id="_9732"/>
<xs:enumeration value="local police units" id="_9733"/>
<xs:enumeration value="ambulance units" id="_9734"/>
<xs:enumeration value="rescue units" id="_9735"/>
<xs:enumeration value="fire units" id="_9736"/>
<xs:enumeration value="hAZMAT units" id="_9737"/>
<xs:enumeration value="light tow unit" id="_9738"/>
<xs:enumeration value="heavy tow unit" id="_9739"/>
<xs:enumeration value="freeway service patrols" id="_9740"/>
<xs:enumeration value="transportation response units" id="_9741"/>
<xs:enumeration value="private contractor response units" id="_9742"/>
</xs:restriction>
</xs:simpleType >
<xs:simpleType>
