ITIS Phrase Tables, Draft [issued: 04-11-09]
-
156 -
This is a draft document of the SAE ATIS committee, subject to change.
pass-with-care (12296), -- NEW: R-??
... -- # LOCAL_CONTENT_ITIS
}
XML Representation:
<xs:simpleType name="RegulatorySigns" >
<xs:union>
<xs:simpleType>
<xs:restriction base="xs:unsignedInt">
<xs:minInclusive value="12288"/>
<xs:maxInclusive value="12543"/>
</xs:restriction>
</xs:simpleType>
<xs:simpleType>
<xs:restriction base="xs:string">
<xs:enumeration value="regulatory sign" id="_12290"/>
<xs:enumeration value="divided road" id="_12291"/>
<xs:enumeration value="double arrow" id="_12292"/>
<xs:enumeration value="dead end" id="_12293"/>
<xs:enumeration value="no outlet" id="_12294"/>
<xs:enumeration value="wrong way" id="_12295"/>
<xs:enumeration value="pass with care" id="_12296"/>
</xs:restriction>
</xs:simpleType >
<xs:simpleType>
<xs:restriction base="xs:string">
<xs:pattern value="\[.+\].*"/>
</xs:restriction>
</xs:simpleType>
<xs:simpleType>
<xs:restriction base="local:RegulatorySigns" />
</xs:simpleType>
</xs:union>
</xs:simpleType>
In addition, this item may be used by data structures in other ITS standards.
6.32 Data Element: DE_Responder Group Affected
Use: The ITIS enumeration list commonly referred to as "Responder Group Affected," is assigned the
upper byte value of [38] (which provides for value ranges from 9728 to 9983, inclusive). This list is
formally called "ResponderGroupAffected" in the ASN.1 and XML productions. Items from this
enumeration list can be used as an event category classification. This list contains a total of 15 different
phrases. The remaining 112 values up to the lower byte value of [127] are reserved for additional
"national" phrases in this byte range. Local phrases may be added to the list starting with the lower byte
value of 128 and proceeding upward from there (in other words, the first value assigned for any local
additions to this list would be given the value 9856).
ASN.1 Representation:
ResponderGroupAffected ::= ENUMERATED {
emergency-vehicle-units (9729), -- Default phrase, to be used when one of
-- the below does not fit better
federal-law-enforcement-units (9730),
state-police-units (9731),
county-police-units (9732), -- Hint: also sheriff response units
local-police-units (9733),
ambulance-units (9734),
rescue-units (9735),
fire-units (9736),
hAZMAT-units (9737), -- Any vehcile assigned to HAZMAT duties
light-tow-unit (9738),
heavy-tow-unit (9739),
private-tow-units (9743), -- NEW: For 3rd Party tow trucks
freeway-service-patrols (9740),
transportation-response-units (9741),
