ANNEX A-5 LEFT TURN ASSISTANT
Application Description
The Left Turn Assistant provides information to drivers about gaps and speeds of oncoming cars to help them make
a left turn across traffic. This application warns drivers when a collision is probable if the left turn movement is
initiated.
Flow of Events
Flow of events
1.
Oncoming Vehicle “A” sends MSG_BasicSafetyMessageFrame, Part I.
2.
Turning Vehicle “B” receives message
3.
Vehicle “B” recognizes that Vehicle A’s message is relevant (crossing road segment via
map and/or heading and indication of turn)
4.
Vehicle “B” alerts its driver to an oncoming vehicle hazard.
Hardware Devices:
DSRC radio
Positional Sensors
Human-Machine Interface
Occupant
Vehicle
System
Driver
Passenger
Service
Provider
Road
Department
Actors: (What entities play an
active role in use)
X
X
Support information:
CAMP-VSC Task 3 Report, 2003
Concept of Operations
DSRC communications is used to allow the turning vehicle to detect all equipped vehicles in the vicinity.
Furthermore, it allows the turning vehicle to receive the position, velocity, acceleration, and control parameters,
among others, for potential threat vehicles. The in-vehicle unit, based upon the host vehicle’s left turn signal
initiation (and/or possibly other control parameters such as steering wheel angle or yaw rate) constructs a potential
vector for the host vehicle and analyzes the received parameters for the approaching vehicles as contained in their
MSG_BasicSafetyMessageFrame, Part I and MSG_BasicSafetyMessageFrame, Part II messages. The unit also
constructs expected future vectors for these vehicles. If this analysis determines that a collision would be likely if
the left turn movement is initiated, an appropriate warning is issued to the driver
Sensors and Other System Needs
On-board sensors to determine the host vehicle’s intent to turn left, e.g., left turn signal or other control
parameters, may be required.
A map database could help to provide information whether vehicles are in the vicinity of an intersection. If lane
resolution is possible, lane position of left-turning and opposite path vehicles can be used in the algorithm, e.g., if a
left-turning vehicle is in a left-turn pocket and the opposite path vehicle is in a through lane, then the left-turn
warning should actuate.
