SAE J2735-Draft-Rev18 [issued: 06-26-07]
-
32 -
This is an SAE Motor Vehicle Council draft document of the DSRC committee, subject to change.
-- NOTE as the message type is also in the payload,
-- we may want to remove it from here, not sure right now. DCK
wdCount INTEGER (0..1023),
-- a count of bytes to follow
payload OCTET STRING (SIZE(0..1023)),
...
XML Representation:
<xs:element name="nMEA-Corrections" type="NMEA-Corrections"/>
<xs:complexType name="NMEA-Corrections" >
<xs:sequence>
<!-- the specific edition of the standard
that is being sent, normally 2.0 -->
<!-- the message and sub-message type, as
defined in the revision being used
NOTE as the message type is also in the payload,
we may want to remove it from here, not sure right now. DCK -->
<xs:element name="wdCount" >
<xs:simpleType>
<xs:restriction base="xs:unsignedShort">
<xs:maxInclusive value="1023"/>
</xs:restriction>
</xs:simpleType>
</xs:element>
<!-- a count of bytes to follow -->
<xs:element name="payload" >
<xs:simpleContent>
<xs:extension base="payload-string" >
<xs:attribute name="EncodingType" use="required">
<xs:simpleType>
<xs:restriction base="xs:NMTOKEN">
<xs:enumeration value="base64Binary"/>
</xs:restriction>
</xs:simpleType>
</xs:attribute>
</xs:extension>
</xs:simpleContent>
</xs:element>
<xs:simpleType name="payload-string">
<xs:restriction base="xs:base64Binary">
<xs:minLength value="0"/>
<xs:maxLength value="1364"/>
</xs:restriction>
</xs:simpleType >
</xs:sequence>
</xs:complexType>
Remarks: Need to sync this up with a similar message already present in the IEEE 1512 work so they
match.
5.8 Message: MSG_ProbeDataManagement
Use: Taken at a defined snapshot event to define RSU coverage patterns such as the moment an OBU joins
or becomes associated with an RSU and can send probe data.
ASN.1 Representation:
ProbeDataManagement ::= SEQUENCE {
msgID DSRCmsgID, -- This is a unique message
-- identifier, NOT related to
-- the PSID\PSC
sample Sample, -- identifies vehicle
-- population affected
directions Directions, -- Applicable
term CHOICE { -- headings/directions
