SAE J2735-Draft-Rev26 [issued: 09-18-08]
-
204 -
This is an SAE Motor Vehicle Council draft document of the DSRC committee, subject to change.
hozAccelLat (14), -- Lateral Acceleration
hozAccelCon (15), -- Acceleration Confidence
accell4way (16),
confidenceSet (17),
obDist (18), -- Obstacle Distance
obDirect (19), -- Obstacle Direction
yaw (20), -- Yaw Rate
yawRateCon (21), -- Yaw Rate Confidence
dateTime (22), -- complete time
fullPos (23), -- complete set of time and
-- position, speed, heading
position2D (24), -- lat, long
position3D (25), -- lat, long, elevation
vehicle (26), -- height, mass, type
speedHeadC (27),
speedC (28),
... -- # LOCAL_CONTENT
}
-- values to 127 reserved for std use
-- values 128 to 255 reserved for local use
XML Representation:
<xs:simpleType name="VehicleStatusDeviceTypeTag" >
<xs:annotation>
<xs:appinfo>
unknown (0)
lights (1) -- Exterior Lights
wipers (2) -- Wipers
brakes (3) -- Brake Applied
stab (4) -- Stability Control
trac (5) -- Traction Control
abs (6) -- Anti-Lock Brakes
sunS (7) -- Sun Sensor
rainS (8) -- Rain Sensor
airTemp (9) -- Air Temperature
steering (10)
vertAccelThres (11) -- Wheel that Exceeded the
vertAccel (12) -- Vertical g Force Value
hozAccelLong (13) -- Longitudinal Acceleration
hozAccelLat (14) -- Lateral Acceleration
hozAccelCon (15) -- Acceleration Confidence
accell4way (16)
confidenceSet (17)
obDist (18) -- Obstacle Distance
obDirect (19) -- Obstacle Direction
yaw (20) -- Yaw Rate
yawRateCon (21) -- Yaw Rate Confidence
dateTime (22) -- complete time
fullPos (23) -- complete set of time and
-- position , speed , heading
position2D (24) -- lat ,
position3D (25) -- lat ,
vehicle (26) -- height ,
speedHeadC (27)
speedC (28)
</xs:appinfo>
<xs:documentation>
values to 127 reserved for std use
values 128 to 255 reserved for local use
</xs:documentation>
</xs:annotation>
<xs:union>
<xs:simpleType>
<xs:restriction base="xs:unsignedInt">
<xs:minInclusive value="0"/>
<xs:maxInclusive value="28"/>
</xs:restriction>
</xs:simpleType>
 |
